Shear Web Load Cell

Name: Shear Web Load Cell
Brand: N.R. ENTERPRISES
Price: 10000 INR
Availability: InStock

Price 10000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Shear Web Load Cell Specification

Type
Pancake Type Load Cell

Operating Temperature
-10 To 45 Deg C

Usage/Application
Industrial

Safe Overload
150% of Full Scale

Load Capacity
200 Kg to 100 t

IP Rating
IP 67

Excitation Voltage
10-15 VDC

Ultimate Overload
200% of Full Scale

Shear Web Load Cell Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Shear Web Load Cell

A Shear Web Load Cell is a high-precision force measurement device designed to measure compression loads with excellent stability and accuracy. It works by detecting strain generated in the web section when force is applied. These load cells are commonly used in tank weighing, hopper scales, truck scales, and batching systems. Industries such as chemical processing, cement, pharmaceuticals, food processing, and manufacturing rely on shear web load cells for reliable weight monitoring. Their robust stainless-steel construction ensures durability in harsh environments, while their compact design allows easy installation in limited spaces. Shear web load cells provide consistent performance, making them ideal for industrial automation and process control.

Extensive Load Capacity

Our Shear Web Load Cell accommodates diverse industrial needs with its impressive measurement range-from 200 kg to a substantial 100 tons. This versatility makes it well-suited for heavy-duty applications requiring precise and robust force monitoring, ensuring durability and long-term service life.

Superior Safety and Protection

Engineered with safety in mind, the load cell supports safe overloads up to 150% and ultimate overloads up to 200% of its full-scale capacity. With an IP67 rating, it also resists dust and moisture, further protecting sensitive components in challenging industrial environments.

Wide Operational Flexibility

Operating across a temperature range of -10C to 45C, this load cell remains reliable in various climates. It is designed for compatibility with 10-15 VDC excitation voltage, integrating seamlessly into many industrial weighing and force measurement setups.

FAQ's of Shear Web Load Cell:

Q: How is the Shear Web Load Cell typically used in industrial settings?

A: This load cell is commonly utilized in industrial weighing, force monitoring, and process control applications due to its high load capacity and reliability. Its pancake design and robust construction enable accurate measurement in heavy machines, tanks, hoppers, and structural testing systems.

Q: What process should I follow to install the Shear Web Load Cell?

A: Installation involves mounting the load cell securely to a stable base, ensuring proper alignment to avoid side loading. Connect the electrical terminals following the specified excitation voltage (10-15 VDC). It is advisable to refer to the manufacturer's manual for specific wiring and calibration procedures.

Q: When should the load cell be recalibrated to maintain accuracy?

A: The load cell should ideally be recalibrated annually or whenever you suspect measurement drift due to mechanical shocks, overload incidents, or after relocation of the instrumentation to ensure continued precision in readings.

Q: Where can I purchase or source this load cell in India?

A: You can obtain the Shear Web Load Cell from reputable suppliers, exporters, manufacturers, and service providers across India. For the best options, contact specialized industrial measurement equipment vendors or directly approach the manufacturer.

Q: What benefits does the 150% safe overload and IP67 rating provide?

A: A 150% safe overload rating offers enhanced security by allowing temporary overloading without damaging the sensor, vital for dynamic industrial environments. The IP67 rating ensures protection against dust ingress and water immersion, extending the device's operational lifespan.

Q: How does the operating temperature range affect performance?

A: The load cell is engineered to function reliably within -10C to 45C. Operating it within this range guarantees measurement stability, preventing errors caused by temperature-induced material expansion or contraction.
